Disassembly/Reassembly Overview 25
L350/L300/L355/L210/L110 Series Revision B
2.1.5 Checks and Precautions before Disassembling
2.1.5.1 Factors which Affect the Print Quality
HOW TO PLACE THE INK TANK ASSY WHEN DISASSEMBLING/REASSEMBLING
The film under sealing film attached on the Ink Supply Tank Assy of this printer is ventilation film. The ink in the
ink tanks is vented to atmosphere through this film to keep ink supply to the Printhead stable. If the film gets wet
with ink, the ink in the tanks is not properly vented and printing may not be capable.
In order to prevent this from occurring, make sure to place the Ink Supply Tank Assy as shown below after
removing it.
Figure 2-8. How to Place the Ink Tank Assy
Ink Supply Tank Assy
Ink Supply Tank Assy
Ink Supply Tank Assy
Ventilation film
Do not place the Ink Supply Tank Assy with its film side down.
Otherwise, ink in the Ink Supply Tank Assy may reach and
cover the ventilation film, and the printing failure may occur.
OK
NG

Epson L351 Specifications

General

Print Technology	Inkjet
Print Resolution	5760 x 1440 DPI
Print Method	On-demand inkjet (Piezo electric)
Output Paper Tray Capacity	30 sheets
Ink Tank Capacity (Black)	70 ml
Print Speed (Black)	33 pages/min Monochrome
Print Speed (Color)	15 pages/min Colour
Connectivity	USB
Minimum Ink Droplet Volume	3 picoliters
Black Nozzle Configuration	180 nozzles
Colour Nozzle Configuration	59 Nozzles per colour
Photo Print Speed	Approx. 69 seconds per 10 x 15 cm photo
Paper Formats	A4, A5, A6, B5, Letter, Legal, 10 x 15 cm, 13 x 18 cm, 16:9, Envelopes (DL, COM10)
Input Paper Capacity	100 sheets
Functions	Print, Copy, Scan
Copy Speed (Black)	Approx. 5.0 ipm (ISO/IEC 24734)
Ink Tank Capacity (Color)	70 ml (per colour)
