Epson M105 Service Manual

Confidential
Disassembly/Reassembly Overview 24
M200 / M205 / M100 / M105 Series Revision A
Housing Ink Supply Tank 1:32 1:32
ADF/SCN Unit 2:46 2:52 5:38
ADF Unit
3:32 2:52 6:24
ADF Hinge Left 5:28 5:28
ADF Document Support
7:06 7:06
ADF Hinge Right 3:53 3:53
Cover Gear Assy 4:29 4:29
Bevel Gear Shaft
4:34 4:34
Combination Gear 24.9.6 4:33 4:33
ADF Frame Assy 5:04 5:04
ADF Front Frame 6:00 6:00
Spur Gear 20.4 / 25.8 6:04 6:04
ADF Driven Gears 6:42 6:42
ADF Upper Frame Assy 6:44 6:44
ADF Pad Assy
7:23 7:23
ADF Base Assy 6:15 6:15
Scanner Unit
3:30 2:52 6:22
Scanner Housing Upper 5:05 5:05
CIS Module Unit 5:28 5:28
Spacer 5:44 5:44
CIS Module 5:44 5:44
Scanner Motor Gear Cover 5:58 5:58
Combination Gear 18.4.9.66 6:05 6:05
Scanner Carriage Unit 6:09 6:09
Scanner Motor 8:25 8:25
CIS Holder Unit 8:25 8:25
Scanner Housing Lower 6:09 6:09
Housing Left
4:19 4:19
Ethernet Cover 4:25 4:25
Panel FFC Cover
3:04 3:04
Hinge 3:02 3:02
Housing Right 5:32 5:32
Strengthen Plate Upper 4:09 4:09
Strengthen Plate Lower 4:10 4:10
Cap Assy
5:06 5:06
Cap Lever 5:15 5:15
Porous Pad for Cap Assy
5:21 5:21
Star Wheel Holder Assy 1:52 3:18 5:10
EJ Roller 3:48 3:18 7:04
Panel Unit 5:27 5:27
Panel Housing Upper Assy 6:01 6:01
Panel Board 7:33 7:33
Panel Button 9:04 9:04
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson M105 Specifications

General

Print Technology	Inkjet
Print Speed Black	Up to 34 ppm
Print Resolution	1440 x 720 dpi
Connectivity	USB 2.0
Duplex Printing	Manual
Ink Type	Pigment-based
Ink Colors	Black
Functions	Print
Weight	3.4 kg
Print Speed	Up to 34 ppm
Print Speed (Color)	Up to 18 ppm
Paper Size	A4, A5, A6, B5, DL
Input Tray Capacity	100 sheets
Operating System Support	Windows, macOS
