Confidential
Disassembly/Reassembly Overview 25
M200 / M205 / M100 / M105 Series
Revision A
Panel Housing Upper 9:04 9:04
Housing Front 7:00 7:00
Main Board FFC Holder 4:45 4:45
Ethernet Board Assy
5:05 5:05
Wireless LAN Module 4:53 4:53
EJ Roller Gear 4:33 4:33
PF Motor Cover
4:28 4:28
PS Unit 4:41 1:28 6:09
PF Scale Sheet 4:29 4:29
PF Encoder Sensor 4:43 4:43
PF Scale 4:55 4:55
PF Grounding Spring 5:02 5:02
PF Driven Pulley Assy 5:39 1:10 6:49
PF Timing Belt 6:26 1:10 7:36
Hopper
5:00 3:03 8:03
LD Roller Assy 7:30 0:47 8:17
Spur Gear 37.2
7:34 7:34
Extension Spring 0.137 7:46 7:46
Clutch 7:50 7:50
LD Roller Shaft Assy
7:50 7:50
Shield Plate 7:43 7:43
Main Board
EEPROM Data Copy OK 8:39 1:10 9:49
EEPROM Data Copy NG 8:39 28:27 37:06
CR Motor
9:08 1:00 10:08
PE Sensor Lever 10:05 0:47 10:52
CR Scale 9:16 3:07 12:23
CR Driven Pulley Assy 9:48 9:48
CR Scale Cover Frame 8:35 8:35
LD Roller Cover 8:59 8:59
FFC Holder 9:06 9:06
Main Frame Assy 16:06 12:45 28:51
Antistatic Cloth 14:40 14:40
Paper Guide Upper Assy
18:54 8:50 27:44
CR Unit 17:42 11:21 29:03
CR Timing Belt 17:56 0:40 18:36
CR Encoder Sensor 18:08 18:08
Head FFC
17:42 17:42
Frame Base Assy 14:12 7:28 21:40
Pomp Unit
17:13 17:13
Spur Gear 16.5 17:22 17:22
PF Roller Unit
20:21 5:51 26:12
PF Motor Assy 21:12 1:08 22:20
Frame Base 21:12 6:53 28:05
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
