5 Remote receiver

6 Speaker

7 HDMI port (EX3260/EX5260/VS250/VS350/VS355); HDMI/MHL port (Pro EX7260); HDMI1 and

HDMI2/MHL ports (Pro EX9210/Pro EX9220)

8 Computer port

9 USB-B port

10 USB-A port

Parent topic: Projector Part Locations

Projector Parts - Base
