G LAN port
Connect the LAN cable here.
H Data light
Indicates the network connection status and data reception by lighting or flashing.
On : Connected.
Flashing : Receiving data.
I Status light
Indicates the network transmission speed by the color of the light.
Green : 10Base-T
Red : 100Base-T
J USB port
Connect the USB cable here.
K Air inlet
Lets in the air to cool down the printer. Do not block the air inlet.
SC-F2100 Series User's Guide
Introduction
13
