The status of wired LAN network connections is shown by the following icons.
Connection on:
Connection off:
Press this area while either of the above icons is displayed to open the Network Settings setup screen. When the
icon looks like
, it is disabled.
K (Inside Light)
Switches the internal lamp on or off. Press this button to turn off the inside light, when it is on. Pressing it while the
inside light is off, turns it on. It may not light, even if you turn it on, depending on the state of printer operations.
When receiving print jobs
When a print job is sent to the printer, the screen changes to the preview screen (screen below on the left). After a job is
received, starting printing by pressing the x button changes the screen to the information screen (screen below on the
right).
This section explains only the differences from other screens.
A Image preview area
You can check a preview image of the print job. The number of prints is shown on the left side of the preview
image.
B Print settings confirmation area
Displays the media settings selected on the printer and the print job.
C (Switch display)
Each time this button is pressed, the display switches between the information screen and the preview screen.
This button is only enabled when a print job has been received.
SC-F3000 Series User's Guide
Introduction
20
