SC-F9200 Series Rev.A
13
Tighten 3screws with washer
Peel tapes off as below.
Open the front cover.
Be careful not to trap your hands or fingers when opening or
closing the front cover.
C A U T I O N
Pressing the tabs on both sides of the media holding plates to center
as shown. Temporarily in the center of the platen before adjustment
of parallelism (Reel/Roll/Media Guide bar).
The media holding plate is used when printing on media
with a thickness of less than 0.4 mm.
C H E C K
P O I N T
To Next Page
