Pressing this button displays the Media Setup
menu on the screen to perform Feed To Cut
Position, Media Remaining, Select Media,
Customize Settings, and Easy Media Setup.
U “The Media Setup Menu” on page 94
If you press this while printing, you can adjust the
media feed.
U “Correcting Banding” on page 51
D Display
Displays the printer's status, menus, error
messages, and so on. U “Understanding the
Display” on page 14
E Menu button
Press this button to display menus. U “Using the
Control Panel Menu” on page 88
F y button (back button)
Press this button to exit to the previous menu
when options are displayed. U “Menu
Operations” on page 88
G
l/r buttons (left and right arrow buttons)
Use to position the cursor when performing such
tasks as entering a Setting Name or IP address in
the setup menu.
H
u/d buttons (up and down buttons)
❏ When the media loading lever is in a lowered
position and the d button is pressed, media is fed. If
the u button is pressed, media is rewound. This
occurs regardless of the way the loaded media is
rolled.
Note that when the u button is used to rewind, the
media will stop when its edge reaches the starting
print position. Rewind can be resumed by releasing
the button and then pressing it again.
❏ When the media loading lever in a raised position,
the button to rewind media depends on how the
loaded media is rolled.
Printable Side Out: Press the u button.
Printable Side In: Press the d button.
Keep the button pressed to rewind the media up to
25 cm.
❏ When the menus are displayed, these buttons can
be used to select menu items and options. U
“Menu Operations” on page 88
I Z button
❏ Pressing this button when a menu item is
highlighted displays options for the selected item.
❏ Pressing this button when an option is highlighted
selects the highlighted item or performs the
selected operation.
❏ Pressing this button while the alert buzzer is
sounding stops the buzzer.
J button (heating/drying button)
The Heating & Drying menu appears, and you can
do Start Preheat, Heater Temperature, Blank
Area Feed, Drying Time Per Pass, and After
Heater Feed. You can only set Heater
Temperature while printing.
U “Changing the Heater's Temperature” on
page 50
K # button (maintenance button)
The Maintenance menu appears, and you can do
Nozzle Check, Cleaning, Head Maintenance,
Waste Ink Bottle Replacement, Head Cleaning
Set, and Other Maintenance. Operations do not
occur while printing, no matter which button is
pressed.
U “The Maintenance Menu” on page 104
L W button (pause/cancel button)
SC-F9300 Series User's Guide
Introduction
13
