C
Pull off the transparent flange from the spindle.
D
Attach or remove the attachments in accordance
with the roll core size of the roll paper.
2 inch roll core
The attachments are not required. Remove the
attachments from the flanges if they have been
attached to the flanges.
Push the two tabs on the flange outwards to
remove the attachment.
After you remove the attachment from the black
flange, remove the attachment from the spindle.
3 inch roll core
Attach the attachments to the both flanges. Align
the triangle marks on the flange with those on the
attachment, and push in until the tabs are
secured.
E
Place the roll paper on a flat surface and then
insert the spindle.
With the black flange is on the right, orient the
roll paper so that the leading edge is as shown in
the figure below.
F
Push the flange to the roll paper until there is no
gap between the flange and roll paper.
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series/SC-T3400N Series User's Guide
Loading and Setting the Paper
36
