Epson Stylus COLOR 3000 Manual

EPSON Stylus COLOR 3000
12 - EPSON Stylus COLOR 3000 5/97
5. You see an installation instruction screen. Follow the
instructions on the screen to install the utility on your
computer’s hard disk drive.
6. Once the utility is installed, log onto the directory you
specified for the utility. Then type
EPCALIB and press
Enter to start the program.
Note:
You can use a mouse with the utility if you have a DOS mouse driver
installed.
7. You see the EPSON Print Head Alignment Utility main
screen. Make sure your printer is listed on the screen and
select
Next.
8. Follow the instructions on the utility screens to align your
print heads.
Using the Control Panel
1. Load several sheets of paper, at least 8.3 inches (210 mm)
wide, into the paper tray, making sure the edge guides are
positioned correctly and the paper-release lever is set to the
singular sheet position.
2. Turn off your printer.
3. Hold down the
Pause button and turn on the printer to
turn on print head alignment mode. Be sure to hold down
both buttons for three seconds before releasing them.
The printer loads a sheet of paper and prints an instruction
sheet telling you how to select a language (the default
setting is English).
4. If you want to print the instructions in another language,
press the
Micro Adjust U button until the Ink Out B
Yellow and Ink Out B Magenta lights on your control
panel indicate the language you want to use.
English Both lights off
French
Ink Out B Yellow on
and
Ink Out B Magenta off
German
Ink Out B Yellow flashing
and
Ink Out B Magenta off
Italian
Ink Out B Yellow off
and
Ink Out B Magenta on
Spanish Both lights on
Portuguese
Ink Out B Yellow flashing
and
Ink Out B Magenta on
5. Press the
Pause button. The printer prints instructions on
aligning the print heads using the control panel.
6. Follow the instructions on the sheet. When the print heads
are aligned, turn off the printer to exit print head alignment
mode.
7. After five seconds, turn on the printer to resume printing.
Transporting the Printer
Caution:
If you don’t follow the procedures in this section, ink
will leak when you transport the printer.
However, if you are moving your printer a short
distance, for example, from one table to another, you
don’t need to remove the ink cartridges. Be sure to
keep the printer level when you move it.
If you want to ship your printer, you need to prepare it for
transportation and repack it in the original box. Follow these
steps:
1. Turn on the printer.
2. Remove all four of the ink cartridges and store them in
separate plastic bags.
3. Close the ink compartment door.
4. Turn off the printer and make sure the print heads are in
the home (far right) position. If they are not, turn the
printer back on, wait until they stop moving and are in the
home position, then turn off the printer.
5. Wait until the printer stops making noise and all the lights
stop flashing, then unplug the power cord from the
electrical outlet and disconnect the interface cable from the
printer.
6. Remove the paper from all the feeders.
7. Remove the edge guides and banner paper cover.
8. Remove the paper tray and paper tray cover.
9. Repack the printer and attachments in the original box
using the protective materials that came with it. See the
Notice Sheet that was packed with the printer.
Be sure to keep the printer level in an upright position as you
transport it.
If you reinstall the cartridges that were removed in step 2, the
ink sensor will not correctly indicate the amount of ink in the
cartridges. You may run out of ink before the
Ink Out lights
comes on. If you want the ink sensor to work properly, you
need to install new ink cartridges. See page 9 for instructions.
Related Documentation
TM-STYCLR3000EPSON Stylus COLOR 3000
Service Manual
PL-STYCLR3000 EPSON Stylus COLOR 3000
Parts Price List
4007168 EPSON Stylus COLOR 3000
User’s Guide
4007164 EPSON Stylus COLOR 3000
Quick Setup booklet

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
