Epson Stylus COLOR 3000 Manual

EPSON Stylus COLOR 3000
6 - EPSON Stylus COLOR 3000 5/97
Lights Buttons
Operate
The Operate light is on when the
printer is on. When the
Operate
light flashes, the printer is
receiving data. It may also flash
with other lights during certain
operations or error conditions.
Paper Out S
When the Paper Out light comes
on, your paper ran out or is
loaded incorrectly, or the paper-
release lever is set to the wrong
position. Load paper, check the
lever position, and then press the
Pause or Load/Eject button to
turn off the light.
When the
Paper Out light flashes,
you have a paper jam. Turn off
the printer and gently pull out all
jammed paper and reload the
paper.
Ink OutBYellow
BMagenta
BCyan
BBlack
When an Ink Out light flashes,
your ink supply is low. Make sure
you have a replacement cartridge.
When an
Ink Out light comes on,
you need to replace the ink
cartridge.
Pause
When the Pause light is on,
printing is paused. Press the
Pause button to resume.
When the
Pause light flashes,
your printer is charging ink,
cleaning the print heads, or
performing another operation.
Plain Paper
360 DPI Ink Jet Paper
Photo Quality Ink Jet
Paper
Photo Quality Glossy
Film
Ink Jet Transparencies
Other/Media Selection
Off
The Media Type light indicates
which media you selected with
the Media Type button. When
you print, the printer software
checks the software setting and
this selection to see if they match.
If they do not match, an error
message appears on your screen. If
you do not want to use this
feature or your media is not listed,
select
Other/Media Selection
Off
.
All the lights
When all the lights flash, your
printer may have an internal
error.
Operate P
Turns the printer on and off.
LF/FF
Feeds paper line by line. Loads a single
sheet or advances continuous or banner
paper to the next top-of-form position
if held down.
Load/Eject
When paper is not loaded, loads a sheet
of paper or a single sheet of continuous
paper.
When paper is loaded, ejects a sheet of
paper. Feeds continuous paper
backward to the paper-park position.
Ejects banner paper backward. Feeds
continuous or banner paper to the tear-
off position when pressed after printing
and Auto tear-off mode is set to off in
default-setting mode.
Pause/Reset
Stops printing temporarily. Resumes
printing when pressed again.
Clears the printer buffer if pressed for
five seconds.
Micro Adjust D
Micro Adjust U
Adjusts the loading position or tear-off
position for continuous paper. Press
the
Micro Adjust D button to feed
paper forward or press
Micro Adjust U
to feed paper backward.
Micro Adjust settings are saved in the
printer’s memory.
Cleaning B
Starts the black print head cleaning
cycle if pressed for three seconds. See
“Cleaning the Print Heads” on
page 10.
Cleaning A
Starts the color print head cleaning
cycle if pressed for three seconds. See
“Cleaning the Print Heads” on
page 10.
Media Type
Determines whether the Media Type
setting you selected in the printer
driver matches the type of media
loaded in the printer.
If paper is loaded and the Media Type
lights flash, the paper-release lever is
not in the correct position. Match the
paper-release lever position with the
media type and paper source you are
using.
Note:
The Media Type setting only works when printing from the paper
tray with Windows 95 or Macintosh.

Epson Stylus COLOR 3000 Specifications

Printing Resolution

maximum resolution	1440 x 720 dpi
driver setting resolution	720 x 720 dpi
printable width	410 mm

Paper Handling

paper capacity (plain paper)	100 sheets
paper capacity (EPSON Inkjet transparencies)	30 sheets
paper capacity (envelopes)	10 envelopes

Ink Cartridges

black ink cartridge print capacity	Up to 3, 000 pages (A4, text @ 360dpi)
colour ink cartridges print capacity	Up to 2, 100 pages (A4, 360dpi 5% duty each colour)
colour ink cartridges	Cyan, Magenta, Yellow

Operating Environment

operating temperature	10-35°C
operating humidity	20-80% RH
total print volume	75, 000 pages (A3, text only)

Electrical Specifications

rated voltage	AC 220V-240V
rated frequency	50-60 Hz
power consumption	Approx. 21W (ISO 10561 letter pattern)

Weight and Dimensions

weight	18 Kg
width	810 mm
depth	565 mm
height	240 mm
