Epson Stylus Pro 9900 Brochure & Specs

PRODUCTNAME
Epson Stylus Pro 7900
SIZE
24 inch wide
INK MODE
10 Colour (11 inks onboard)
Auto switching between Photo and Matte Black
PRINTTECHNOLOGY
Print Head
Nozzle Configuration
Print Direction
MicroPiezo
™
TFP (Thin Film Piezo) Print Head
360 nozzles per colour
Bi-directional printing, uni-directional printing
PRINT RESOLUTION
Maximum resolution
Maximum Ink Droplet Size
2880dpi x 1440dpi Epson Variable-sized
Droplet Technology
3.5pl
INKSYSTEM
Ink type
Configuration
Ink Cartridge
Ink Capacity
Epson UltraChrome
™
HDR
(High Dynamic Range) Ink
10-Colours pigment ink (C, M, Y, PK, MK, LC,
LM, LK, LLK O, G) with 11 slots)
Auto switching between Photo and Matte Black
Individual high capacity hot swappable ink
cartridge 350ml or 700ml
PRINTER SPEED – A1 SIZE
Draft (360 x 360dpi)
Fine (720 x 720dpi)
Super fine (720 x 1440dpi)
Super Photo (2880 x 1440dpi)
0.8 minutes
4.5 minutes
6.8 minutes
13.4 minutes
PRINTER DRIVER
Win2000, XP(32bit/64bit), MacOSX 10.3.9
or later
PAPERINPUTCAPABILITY
Roll Media Single roll
1 roll < 170mm /
Outside diameter
Media width
254mm-620mm
Maximum Media Thickness
0.8mm-1.5mm
PAPEROUTPUTCAPABILITY
Output bin, Rotary cutter blade, single roll
system
PRINTINGAREA(WIDTH)
Maximum paper width Roll Paper
406mm-610mm, 2 / 3 inch core
Cut Sheet 210mm-610mm
CONSUMABLESPARTS
Cutter blade, maintenance tank
MAINTENANCEPARTS
Pump unit, flushing box, head cleaner, cap
assembly
RELIABILITY
Cutter Blade
Carriage Motor
Coat paper, approx. 2000 cuts
Approx. 20,000 B0+ sheets
CONTROLPANEL
Colour
Size
2.5 inch LCD screen
320 x 200 pixels
ROLL DIMENSIONS
Core diameter 2” or 3”, Max. Outside Diameter
Ø 150mm
MEMORY
Printer
Network
256MB
64MB
LANGUAGES
ESC / P2 Raster
INTERFACES(STANDARD)
USB2.0 (Compatible with 1.1)
Ethernet 10 Base-T 100 Base-TX
VOLTAGE/CURRENT
AC 100-120V / 220-240V
POWERCONSUMPTION
Operating
Sleep
Standby
Sleep
70W
<16W
<1W
<16W
DIMENSIONS
1356 x 667 x 1218 (mm)
WEIGHT
Printer: 84.5kg (includes stand)
WARRANTY
Standard 1 year onsite
PRODUCTNAME
Epson Stylus Pro 9900
SIZE
44 inch wide
INK MODE
10 Colour (11 inks onboard)
Auto switching between Photo and Matte Black
PRINTTECHNOLOGY
Print Head
Nozzle Configuration
Print Direction
MicroPiezo TFP (Thin Film Piezo) Print Head
360 nozzles per colour
Bi-directional printing, uni-directional printing
PRINT RESOLUTION
Maximum resolution
Maximum Ink Droplet Size
2880dpi x 1440dpi Epson Variable-sized
Droplet Technology
3.5pl
INKSYSTEM
Ink type
Configuration
Ink Cartridge
Ink Capacity
Epson UltraChrome HDR
(High Dynamic Range) Ink
10-Colours pigment ink (C, M, Y, PK, MK, LC,
LM, LK, LLK O, G) with 11 slots)
Auto switching between Photo and Matte Black
Individual high capacity hot swappable ink
cartridge 350ml or 700ml
PRINTER SPEED – A1 SIZE
Draft (360 x 360dpi)
Fine (720 x 720dpi)
Super fine (720 x 1440dpi)
Super Photo (2880 x 1440dpi)
0.8 minutes
4.5 minutes
6.8 minutes
13.4 minutes
PRINTER DRIVER
Win2000, XP(32bit/64bit), MacOSX 10.3.9
or later
PAPERINPUTCAPABILITY
Roll Media Single roll
1 roll < 170mm /
Outside diameter
Media width
254mm-620mm
Maximum Media Thickness
0.8mm-1.5mm
PAPEROUTPUTCAPABILITY
Output bin, Rotary cutter blade, single roll
system
PRINTINGAREA(WIDTH)
Maximum paper width Roll Paper
406mm-1118mm, 2 / 3 inch core
Cut Sheet 210mm-1118mm
CONSUMABLESPARTS
Cutter blade, maintenance tank
MAINTENANCEPARTS
Pump unit, flushing box, head cleaner, cap
assembly
RELIABILITY
Cutter Blade
Carriage Motor
Coat paper, approx. 2000 cuts
Approx. 20,000 B0+ sheets
CONTROLPANEL
Colour
Size
2.5 inch LCD screen
320 x 200 pixels
ROLL DIMENSIONS
Core diameter 2” or 3”, Max. Outside Diameter
Ø 150mm
MEMORY
Printer
Network
256MB
64MB
LANGUAGES
ESC / P2 Raster
INTERFACES(STANDARD)
USB2.0 (Compatible with 1.1)
Ethernet 10 Base-T 100 Base-TX
VOLTAGE/CURRENT
AC 100-120V / 220-240V
POWERCONSUMPTION
Operating
Sleep
Standby
Sleep
80W
<16W
<1W
<16W
DIMENSIONS
1864 x 667 x 1218 (mm)
WEIGHT
Printer: 116kg (includes stand)
WARRANTY
Standard 1 year onsite
Epson Stylus
™
Pro 7900 | 9900
Specifications
11/08
ABN: 91 002 625 783
Epson Australia 1300 131 928
Epson New Zealand 0800 23 77 66
www.epson.com.au
* LIGHTFASTNESS TEST
CRITERIA (INDOOR DISPLAY
CONDITION)
Test Conditions
1. Under fluorescent light
(Indoor Display Condition)
with glass mount.
2. The data is calculated
by Epson’s accelerated test
and it does not mean Epson
guarantees periods.
3. The estimated longevity
does not indicate the colour
changing and the durability of
the paper itself.
Light Source: Fluorescent
LightIntensity: 70,000
luxTemperature: 24°C
Humidity: 60%RH
Glass mount: 2mm, soda lime
Fade criteria: Pure YMC 30%
loss at OD = 1Display-life
calculation: Total illuminance/
(500lux x 10hours x 365days =
1year)
As an International ENERGY
STAR Partner, Epson has
determined that this product
meets the International
ENERGY STAR guidelines for
energy efficiency. Epson is
the registered trademark of
SEIKO Epson Corporation.
Epson Stylus, PerfectPicture,
MicroPiezo, AcuPhoto
Halftoning, QuickDry are the
trademarks of SEIKO Epson
Corporation. All other names
and company names used
herein are for identification
purpose only and may be
the trademarks or registered
trademarks of their respective
owners. Epson disclaims
any and all rights in those
marks. All print samples
shown herein are simulations.
Specifications are subject to
change without notice.

Epson Stylus Pro 9900 Specifications

General

Color	Yes
Maximum resolution	2880 x 1440 DPI
Media thickness	0.08 - 1.50 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll width	1118 mm
Display	LCD
Internal memory	64 MB
Country of origin	China
Drive device, buffer size	256 MB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Fast Ethernet
Compatible operating systems	Microsoft Windows 2000, XP, XP 64-bit, Vista, MAC OSX 10.x.x
Power requirements	AC 100-240V 50/60Hz
Power consumption (active)	80 W
Power consumption (standby)	1 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	2040 mm
Package width	815 mm
Package height	1080 mm
Package weight	193053 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Dimensions (WxDxH)	1702 x 678 x 1196 mm
