DISASSEMBLY/ASSEMBLY Overview 63
Confidential
4.1.4 Procedural Differences
The disassembly/reassembly procedures of NX100 series and NX110 series are different. Unless otherwise specified, this chapter describes NX100 series. Refer to the pages
mentioned below for the disassembly/reassembly procedures of NX110 series.
Table 4-3. Procedure Differences
Parts name Differences Reference page
Panel Unit
The shapes and positions of the button on the Panel Unit are different. (See
“ 1.6 Control Panel ” ( p. 21 ) for the shapes of the Panel Unit.)
NX100 series
“ 4.4.1 Panel Unit ” ( p. 72 )
NX110 series
“ 4.4.1 Panel Unit ” ( p. 72 )
