Epson TM-J7100 - Slip Paper Feed Specifications; Slip Printable Area

4-8 Specifications Rev. A
Confidential
Paper Feed Specifications
lps: lines per second
Printable Area
Printable area
Note:
The values shown in this figure are calculated ones. Consider this for the user design for the print starting
position in the paper feeding direction.
Paper Feed Specifications
Item Specifications
Paper feed method Friction feed
Paper feed direction Bidirectional
Feeding pitch Approx. 0.1411 mm (1/180 inch)
Continuous feed speed Approx. 150 mm/s (approximately 5.9 inches/s) at 35.4 lps
The first printing
line
p
osition
TOF sensor position
Form stopper
position
Paper feeding
roller position
The last printing line
position
BOF sensor position
[U
n
i
ts: mm
]
36
(
255 ste
p
s
)
63.4
(
449 ste
p
s
)
