4-4 Specifications Rev. A
Confidential
Character Specifications
* : Using the memory switch for characters per line
Note:
The number of characters (columns) per line is selectable by a memory switch.
Selection of characters per line can be performed for receipt and slip (including endorsement).
If memory switch changing of characters per line is performed, one dot on the right side of a graphic
character or user-defined character may be missed.
The actual print character may be smaller than the size shown in the table above, because the above size includes
spaces in the font.
Characters can be scaled up to 64 times as large as the standard size.
Character size not including the horizontal spacing in the standard scale is as follows:
Font A:1.41 (W) × 3.384 (H) mm
Font B: 0.987 (W) × 2.397 (H) mm
Character Specifications
Item Specifications
Character type Alphanumeric 95 characters
International 37 types
Extended graphics 128 characters ✕ 11 pages
(including one user-defined page)
Character structure See "Character Configurations and Dimensions" table
below. (Default is Font A.)
Character dimensions See "Character Configurations and Dimensions" table
below. (Spaces between characters not included.)
Character structure
Font A Font B * Font A * Font B
Dot configuration
H ✕ V (includes 2-dot H space)
12 ✕ 24 9 ✕ 17 11 ✕ 24 8 ✕ 17
Character size
Standard Double-height Double-width
Double-width /
Double-height
W × H (mm) W × H (mm) W × H (mm) W × H (mm)
Font A (12 × 24) 1.69 × 3.38 1.69 × 6.77 3.38 × 3.38 3.38 × 6.77
Font B (9 × 17) 1.27 × 2.40 1.27 × 4.80 2.54 × 2.40 2.54 × 4.80
* Font A (11 × 24) 1.55 × 3.38 1.55 × 5.77 3.10 × 3.38 3.10 × 6.77
* Font B (8 × 17) 1.13 × 2.40 1.13 × 4.80 2.26 × 2.40 2.26 × 4.80
