Epson TM-m30II User Manual

41
Chapter 2 Setup
Setting up from a Windows Computer
Necessary Items
Prepare the following items.
• Computer for setting: Windows 10/8/7
Computer equipped with a wireless LAN function
• Utility for setting: EpsonNet Config or EpsonNet Config (Web version)
Follow the steps below to connect the printer.
1
Turn on the printer.
After starting the printer, check that the "SimpleAP Start" is printed.
If it is not printed, enter the Interface Setup mode and restart the printer in the SimpleAP mode. For
more details, see "Interface Setup Mode" on page 67.
2
Activate Windows Wireless Network Connection and select [EPSON_Printer] as the
connection device on the screen that appears.
If the window to enter a pass phrase appears, enter "12345678”.
Default settings on printer are the following values.
3
When connecting to the printer is complete, setup the Wireless LAN using the
network setup tool, EpsonNet Config or EpsonNet Config (Web version).
For details about EpsonNet Config, see "Setup using EpsonNet Config" on page 57.
For details about EpsonNet Config (Web version), see "Setup using EpsonNet Config (Web version)"
on
page 58.
4
When setting the Wireless LAN is complete, restart the printer.
Network mode SimpleAP mode
SSID EPSON_Printer
Pass phrase 12345678
IP Address 192.168.192.168

Epson TM-m30II Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
Maximum printing width	80 mm
Power plug type	Type G
Power source type	AC
USB port	Yes
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Internal memory	- MB
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Pre-installed software	TMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print
Package depth	240 mm
Package width	200 mm
Package weight	2150 g
Quantity per pack	1 pc(s)
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
