Epson TM-m30II User Manual

54
Chapter 3 Advanced Usage
Optional buzzer
Enables/disables
• Disabled (initial setting)
• Enabled
Buzzer frequency (Error)
• Does not sound
• Sounds 1 time
• Sounds continuously (initial setting)
Sound pattern (Autocut)
Selectable from Patterns A to E
Initial setting: Pattern A
Buzzer frequency (Autocut)
• Does not sound
• Sounds 1 time (initial setting)
Sound pattern (Pulse 1)
Selectable from Patterns A to E
Initial setting: Pattern A
Buzzer frequency (Pulse 1)
• Does not sound
• Sounds 1 time (initial setting)
Sound pattern (Pulse 2)
Selectable from Patterns A to E
Initial setting: Pattern B
Buzzer frequency (Pulse 2)
• Does not sound
• Sounds 1 time (initial setting)
Batch rotate print (Upside Down)
• Disabled (initial setting)
• Enabled
• For information about how to connect the optional external buzzer, see "Connecting the
Optional External Buzzer" on page 34.
• When
the optional external buzzer is enabled, a cash drawer cannot be used. Be sure to disable
it when you use a cash drawer.

Epson TM-m30II Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
Maximum printing width	80 mm
Power plug type	Type G
Power source type	AC
USB port	Yes
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Internal memory	- MB
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Pre-installed software	TMNet WebConfig, ePOS-Device, ePOS-Display, ePOS-Print
Package depth	240 mm
Package width	200 mm
Package weight	2150 g
Quantity per pack	1 pc(s)
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
