8
English
Hanging the printer on a wall
Follow the steps below to hang the printer on the wall.
!CAUTION:
To fix the printer securely, install printer on a wall made of wood, concrete, or metal. The
thickness of the wall should be 10 mm {0.4"} or more.
Be sure to use metallic screws.
The screws on the wall side must have a pull-out strength of 150 N (15.3 kgf) or more.
1. Install 2 screws (screw diameter: 4 mm {0.16"}, head diameter: 7 to 9 mm {0.28" to 0.35"} in the
wall at an interval of 80 mm {3.15"}. Make sure the length of the screw’s body in the wall is 10
mm {0.39"} or more, and the length outside the wall is 3 to 4 mm {0.12" to 0.16"}.
2. Remove the installed 2 screws from the printer.
80 mm
3 ~ 4 mm
7 ~ 9 mm
4 mm
10 mm or more
