Dip Switch and Paper Near End Settings A-3
Print Density Selection
Notes:
•
With the optional RS-485 interface, DIP switches 2-7 and 2-8 are disabled.
•
Changes in DIP switch settings (excluding switches 2-7 and 2-8 interface reset
signals) are recognized only when the printer power is turned on or when the
printer is reset by using the interface. If the DIP switch setting is changed after
the printer power is turned on, the change does not take effect until the
printer is turned on again or is reset.
•
If you turn on DIP switch 2-7 or 2-8 while the printer is turned on, the printer may
be reset, depending on the signal state. DIP switches should not be changed
while the printer power is on.
•
If the print density is set to level 3 or 4, the printing will be at the low speed.
•
In a low power consuption, printing speed is fixed to 70 mm/sec.
Print Density SW 2-3 SW 2-4
1 Low power comsumption mode ON ON
2(Normal) OFF OFF
3ONOFF
4 (Dark) OFF ON
