Epson TM T88IV User Manual

iv
English
DIP Switch Tables
*1. Only when DIP Switches 1-7 and 1-8 are on, the
transmission speed can be selected from one of
seven speeds: 2400, 4800, 9600, 19200, 38400, 57600,
and 15200 bps. The default is 38400.
Specifications
Serial Interface (DIP switch 1)
SW Function ON OFF
1-1 Data receive error Ignored Prints “?”
1-2 Receive buffer
capacity
45 bytes 4K bytes
1-3 Handshaking XON/XOFF DTR/DSR
1-4 Data word length 7 bits 8 bits
1-5 Parity check Enabled Disabled
1-6 Parity selection Even Odd
1-7
1-8
Transmission speed (See table below.)
Transmission speed
Transmission speed (bps)-bits per second 1-7 1-8
38400 *1 ON ON
4800 OFF ON
9600 ON OFF
19200 OFF OFF
Serial Interface (DIP switch 2)
SW Function ON OFF
2-1 Handshaking
(BUSY condition)
Receive buffer
full
Offline or
Receive buffer
full
2-2 Do not change
2-3
2-4
Print density/
Low power
See Table A
2-5 Release condition
of receive buffer
BUSY (If receive
buffer capacity
set to 4 KB.)
Releases BUSY
when remaining
receive buffer
capacity
reaches
138 bytes.
Releases BUSY
when remaining
receive buffer
capacity
reaches
256 bytes.
2-6 Do not change
2-7 I/F pin 6 reset Enabled Disabled
2-8 I/F pin 25 reset Enabled Disabled
Parallel Interface (DIP switch 1)
SW Function ON OFF
1-1 Auto line feed Always
enabled
Always disabled
1-2 Receive buffer
capacity
45 bytes 4K bytes
1-3 Select paper
sensors to output
paper-end
signals (default
value of ESC C 3)
Disabled Roll Paper end
sensor enabled,
Roll Paper near-
end sensor
enabled
1-4 Error signal output Disabled Enabled
1-5~
1-8
Undefined
Parallel Interface (DIP switch 2)
SW Function ON OFF
2-1 Handshaking
(BUSY condition)
Receive buffer
full
Offline or
Receive buffer
full
2-2 Do not change
2-3
2-4
Print density/
Low power
See Table A
2-5 Release condition
of receive buffer
BUSY (If receive
buffer capacity
set to 4 KB.)
Releases BUSY
when remaining
receive buffer
capacity
reaches
138 bytes.
Releases BUSY
when remaining
receive buffer
capacity
reaches
256 bytes.
2-6
2-7
Do not change
2-8 I/F pin 31 reset (Do not change)
Table A
Print density/low power SW 2-3 SW 2-4
– Low power consumption mode ON ON
Print density “Normal” OFF OFF
Print density “Medium” ON OFF
Print density “Dark” OFF ON
Printing method Thermal line printing
Dot density 180 dpi ×180 dpi [dots per 25.4 mm {1"}]
Printing direction Unidirectional with friction feed
Printing width 80 mm paper width model: 72 mm {2.83"}, 512 dot positions
Characters per line
(default)
80 mm paper width model: Font A: 42; Font B: 56

Epson TM T88IV Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Type	POS printer
Character size	1.1 x 2.1 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL/CSA, TUV
Certification	CE, EN55022, EN55024, RoHS, WEEE
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, PDF417, UPC-A, UPC-E
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	White
Maximum roll diameter	83 mm
Supported paper width	72 mm
Operating temperature (T-T)	5 - 45 °C
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Power supply type	DC
Pallet width	800 mm
Pallet height	1837 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2250 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2780 g
Quantity per pack	1 pc(s)
