17
Product Specifications
*1: The available interfaces vary by the printer model.
*2: This is the average power under our operation conditions. It varies depending on the conditions of use and the model.
Printing method
Thermal line printing
Roll paper Paper width
80 mm paper width setting: 79.5 mm ± 0.5 mm {3.13" ± 0.02"}
58 mm paper width setting: 57.5 mm ± 0.5 mm {2.26" ± 0.02"}
External diameter
Maximum 83 mm {3.27"}
Core internal
diameter
12 mm {0.47"}
Core external
diameter
18 mm {0.71"}
Interface
*1
USB: USB 2.0 Full-speed (12 Mbps)
Ethernet: 10BASE-T/100BASE-TX
Wireless LAN: Connect the optional Wireless LAN unit to the USB
connector.
Power supply
AC ADAPTER,V (DC24V, 2.6A)
Current consumption
2.6 A
AC power consumption
*2
(100 V to 230 V/50 to 60 Hz)
Operating: Approx. 32.0 W
Standby: Approx. 3.0 W
Tem peratu re
Operating: 5 to 45°C {41 to 113°F}
Storage: –10 to 50°C {14 to 122°F}, except for paper
Humidity
Operating: 10 to 90% RH
Storage: 10 to 90% RH, except for paper
Overall dimensions
148 × 145 × 195 mm {5.83 × 5.71 × 7.68"} (H × W × D)
Weight (mass)
Approx. 1.6 kg {3.5 lb}
To Next Page
