Panel Indicator LED's
There are a total of ten (10) LED indicators on the Equalizer Keypad. The function of
these LED's is detailed below.
During typical operation, the LED's on the bottom left hand corner of the keypad should NOT be
illuminated. The only LED that should light is the “OPERATING' LED, which should flash during
operation.
'POWER’ LED ON Red when power is ON
OFF when power is OFF
FLASH every 1 sec. In Sleep Mode
'JACK' LED (4 each) ON Red when jack(s) are deployed
OFF when jack(s) are stowed
'OPERATING' LED ON Red w/ Auto Level or All Retract
OFF when keypad is idle or 'sleeping'
'LOW VOLTAGE' LED ON Red when voltage is below 10.5 VDC
OFF when voltage is above 10.5 VDC
'ENGAGE PARK BRAKE' LED ON Red when park brake is not set
OFF when park brake is set.
'IGNITION ON' LED ON Red when ignition is in the ON position
OFF when ignition is OFF
'EXCESS SLOPE' LED
ON Red following an Auto Level attempt, if
system cannot overcome slope
OFF when slope is not excessive
If the LOW VOLTAGE, ENGAGE PARK BRAKE, IGNITION ON or EXCESS
SLOPE LED's illuminate, you have an 'error' condition that must be corrected prior
to operating the jacks.
11
