There are a total of ten (10) LED indicators on the Equalizer Keypad. The function of
these LED's is detailed below.
During typical operation, the LED's on the bottom left hand corner of the keypad should NOT be
illuminated. The only LED that should light is the “OPERATING' LED, which should flash during
operation.
'POWER’ LED...................................................ON Red when power is ON
OFF when power is OFF
FLASH every 1 sec. In Sleep Mode
'JACK' LED (4 each) .................................... ON Red when jack(s) are deployed
OFF when jack(s) are stowed
'OPERATING' LED ......................................FLASHING Red w/ Auto Level or All Retract
OFF when keypad is idle or 'sleeping'
'LOW VOLTAGE' LED ................................ON Red when voltage is below 10.5 VDC
OFF when voltage is above 10.5 VDC
'ENGAGE PARK BRAKE' LED ...................ON Red when park brake is not set
May not be present on newer trailer OFF when park brake is set.
version units -See Step 9 (installation)
'IGNITION ON' LED ....................................ON Red when ignition is in the ON position
May not be present on newer trailer OFF when ignition is off
version units- See Step 8 (installation)
'EXCESS SLOPE' LED .................................ON Red following an Auto-Level attempt if
system cannot overcome slope
OFF when slope is not excessive
If the LOW VOLTAGE, ENGAGE PARK BRAKE, IGNITION ON or EXCESS SLOPE LED's
illuminate, you have an 'error' condition that must be corrected prior to operating the jacks.
If the jacks down status lights are on (rear lights on trailer version) AutoLevel will be denied. Press
the all retract to clear.
