Equinox Systems Shard - Rear Panel Overview; Component Identification; Package Contents

www.prolight.co.uk Shard User Manual
4
Technical specications
MENU ENTER
MIC
SAFETY EYE
UPDOWN
ON
OFF
POWER OUTPUT:
100-240V~50/60Hz
DMX INPUT
REMOTE
CONTROL
INPUT
DMX OUTPUT
www.prolight.co.uk
POWER INPUT:
100-240V~50/60Hz
FUSE: T1A 250V
03
04
02
09
08
10
01
12
06
07
11
05
01-Earthpoint
02-On/offswitch
03-LEDdisplay
04-Functionbuttons
05-Microphone
06-3-PinDMXinput
07-3-PinDMXoutput
08-IECpowerinput
09-IECpoweroutput
10-FuseT1A250V
11-CA8controlinput
12-Safetyeye
Inthebox:1 x xture,
1 x power cable,
& 1 x user manual
