www.prolight.co.uk Shard User Manual
6
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitof
thextureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonson
therearoftheunittoshowAddrontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstosettherequiredDMXaddress.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
DMX channel mode:
ToaccesstheDMXchannelmode,pressthe“MENU”buttonandusethe“UP”and“DOWN”buttonson
therearoftheunittoshowChNdontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstochooseoneofthe1/4or7DMXchannelmodes.Pressthe“ENTER”
buttontoconrmthesetting.Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions
1 channel mode:
Channel Value Function
Pleasenote:
Allshowsapart
fromShow2
reacttosound.
Show2isa
slowmoving
singlecolour
changeshow
whichdoesn’t
reacttosound.
CH1
000-007 Nofunction
008-037 Show1
038-067 Show2
068-097 Show3
098-127 Show4
128-157 Show5
158-187 Show6
188-217 Show7
218-247 Show8
248-255
Show0
(Randomshow)
7 channel mode:
Channel Value Function
CH1 000-255 Masterdimmer(0-100%)
CH2 000-255 Strobe(slow-fast)
CH3
000-009 Norotation
010-120 Clockwiserotation(fast-slow)
121-134 Norotation
135-245 Counter-clockwiserotation(slow-fast)
246-250 Norotation
251-255 Rotationviasound
CH4 000-255 Red(0-100%)
CH5 000-255 Green(0-100%)
CH6 000-255 Blue(0-100%)
CH7 000-255 White(0-100%)
4 channel mode:
Channel Value Function
CH1
000-016 Red
017-033 Green
034-050 Blue
051-067 White
068-084 Red+Green
085-101 Red+Blue
102-118 Red+White
119-135 Green+Blue
136-152 Green+White
153-169 Blue+White
170-186 Red+Green+Blue
187-203 Red+Green+White
204-220 Red+Blue+White
221-237 Green+Blue+White
238-255 Red+Green+Blue+White
CH2
000-009 Norotation
010-120 Clockwiserotation(fast-slow)
121-134 Norotation
135-245 Counter-clockwiserotation(slow-fast)
246-250 Norotation
251-255 Soundactive
CH3 000-255 Strobe(slow-fast)
CH4
000-015 LEDoff
016-255 LEDon
