EQUIPRITE 5100790 - Page 7

7
Replacement Parts List for Model 5100790
Seal Kit G59510-0000 includes:
Item Part No. Description Qty
1 F36100-0001 Oil Filler Plug 1
2 G59510-0004 Pump Piston 1
3 G48900-0004 Release Valve 1
4 G59305-0002 Snap Ring Φ16 2
5 G80800-0004 Saddle 1
6 G62000-1003 Return Spring 2
7 G58900-0002 Handle Sleeve 1
8 G48900-0015 Pin 1
9 G59305-0003 Nut M10 1
10 G48900-0016 Release Valve Gear 1
11 G59305-0005 Lock Washer Φ10 1
12 G48900-0024 Bolt M10x16 1
13 G48900-0017 Release Valve Connecting Bar 1
14 G59305-0007 E-ring Φ15 2
15 G59305-0004 Washer Φ18 2
16 G59305-0006 Lock Washer Φ20 2
17 G48900-0018 Handle Sleeve Bolt, Left 1
18 G48900-0019 Bolt M12 4
18a G48900-0038 Lock Washer Φ12 4
19 G58900-0003 Tray 1
20 G48900-0001 Return Spring, Handle Sleeve 1
21 G48900-0020 Handle Sleeve Bolt, Right 1
22 G59510-0003 Handle Assembly 1
23 G48900-0006 Caster Assembly 2
24 G59510-0002 Front Wheel Assembly 2
25 G59305-0001 Hydraulic Power Unit 1
26 G59510-0000 Seal Kit (includes # 1, a ~ o) -
Item Description Qty.
1 Oil Filler Plug 1
a O-ring 2
b O-ring 2
c Back-up Washer 2
d Back-up Washer 1
e U-cup 1
f Back-up Washer 1
g O-ring 1
Item Description Qty.
h Back-up Washer 1
i O-ring 1
j O-ring 1
k Back-up Washer 1
l O-ring 1
m O-ring 2
n Back-up Washer 2
o O-ring 1
