PREPARATION
Assembly
Little or no assembly is required. Refer to Figures in the manual for details in understanding the assembly and the
components of your product.
Before Use
1.
Verify that the product and application are compatible, if in doubt contact your local Fastenal Representative or
visit www.fastenal.com to locate your nearest store.
2. Before using this product, read the operator's manual completely and familiarize yourself thoroughly with the
product, its components and recognize the hazards associated with its use.
3. To familiarize yourself with basic operation, locate and turn the release valve knob (see Fig 1):
a. Clockwise until rm resistance is felt to further turning. This is the ‘CLOSED release valve position used to
raise the saddle plate.
b. Counter-clockwise, but no more than 1/2 turn from the closed position. This is the ‘OPEN release valve
position used to lower the saddle plate.
4. With saddle fully lowered, remove the oil ller screw. Pump 6 to 8 full strokes. This will help release any pressurized
air which may be trapped within the reservoir. Check oil level. Proper oil level will vary from just covering the ram
cylinder to 3/16” above it as seen from the oil ller hole. Reinstall the oil ller screw.
5. Ensure that jack rolls freely. Raise and lower the unloaded jack throughout the lifting range before putting into
service to ensure the pump operates smoothly. Replace worn or damaged parts and assemblies with factory
authorized replacement parts only.
Bleeding / Venting Trapped Air
With the release valve in the OPEN position (3b.) and with saddle fully lowered, locate and remove the oil ller
screw. Pump 6 to 8 full strokes. This will help release any pressurized air which may be trapped within the reservoir.
Reinstall the oil ller screw.
! WARNING
Read, understand, and follow all printed material provided with and on this product before use.
Do not exceed rated capacity.
• Use only on hard, level surfaces.
Adequately support the vehicle before starting repairs.
• If loaded jack must be moved, make certain that load is secured by appropriate means, is stable, is in
the lowest possible position, is moved over a smooth, hard level surface and that the lifting platform
is level.
• Use of this product is limited to removal, installation, and transportation of automotive and light
truck transmissions, transfer cases and transaxles.
• Use only adapters / accessories provided by the manufacturer of this transmission jack.
• Use only adapters / accessories whose rated capacity is greater than the rated capacity of this jack.
• Ensure the center of gravity is center loaded on the saddle.
• Never use this device as a work/repair station. Transfer the load immediately to a suitable work station.
• No alteration shall be made to this product.
Failure to heed these markings may result in personal injury and/or property damage.
