4
OPERATION
Follow the instruction for removal and installation of transmission, transfer case or transaxle according to the vehicle
manufacturer's service manual.
Raise saddle:
1. Close release valve by turning release valve knob clockwise rmly.
2. Insert handle into handle sleeve, then pump handle until the load is contacted.
3. Secure load with provided chains.
Ensure center gravity of load is centered on the saddle and load is stable before moving jack. An off-center
transmission could cause the jack to tip or ip over .
Lower saddle:
Be sure all tools and personnel are clear before
lowering load. Slowly open the release valve! The more
you turn the knob counter-clockwise, the faster the load will come down. Maintain control of the rate of
speed at which the load lowers at all times!
1. Secure load to the jack with provided chain.
2. Slowly, gently turn the release valve knob counter-clockwise, never more than 1/2 full turn until the load is
completely lowered.
3. Immediately transfer the load to an appropriate work station.
4. After removing load from the jack, ensure that saddle is fully lowered to reduce ram exposure to rust and
contamination.
Never use this jack as a workstation!
!
!
!
To avoid crushing and related injuries:
•
Never work on, under or around a load supported only by hydraulic jack.
• Be alert and sober when using this product. Do not operate under the
inuence of drugs or alcohol.
! WARNING
MAINTENANCE
Important: Use only good grade hydraulic jack oil. Avoid mixing different types of uid and NEVER use brake uid,
turbine oil, transmission uid, motor oil or glycerin. Improper uid can cause premature failure of the jack and the
potential for sudden and immediate loss of load. Mobil DTE 13M or equivalent recommended.
Adding oil
1. With saddle fully lowered set jack in its upright, level position. Locate and remove oil ller screw.
2. Fill with oil until ~3/16" above the inner cylinder as seen from the oil ller hole. Reinstall oil ller screw.
Changing oil
For best performance and longest life, replace the complete uid supply at least once per year.
1. With saddle fully lowered, remove oil ller screw.
2. Lay the jack on its side and drain the uid into a suitable container.
Note. Dispose of hydraulic uid in accordance with local regulations.
3. Set jack in its level position. Fill with oil until ~3/16" above the inner cylinder as seen from the oil ller hole. Reinstall
oil ller screw
.
