Item Part No. Description Qty.
1 G62-1-1000-108 Hydraulic Unit 1
2 324-4-1900-208 Filler Screw Assembly 1
3 551-7-0060-066 Oil Seal 1
4 G46-3-9906-100 Release Valve Assembly 1
5 G62-6-1401-106 Pump Cylinder 1
6 G62-6-1306-102 Pump Piston 1
7 566-4-0080-508 Pin 3
8 G46-6-1301-205 Handle Sleeve 1
9 649-1-0095-103 Hex socket Set Screw 8
10 G38-3-9901-106 Handle Assembly 1
11 506-9-0264-106 Handle Grip 1
12 G38-4-5200-102 Caster Assembly 1
13 G62-3-4200-101 Saddle Assembly 1
14 G62-5-4302-103 Support Bar 4
15 G52-4-4102-101 Hook & Chain 4
16 G36-6-7000-102 Chain 2
17 G62-3-4502-109 Screw Assembly 4
18 G62-3-4203-109 Saddle Holder 1
19 G62-6-4207-103 Stationary Rod 1
20 G36-3-5100-108 Bearing 1
21 G62-6-4505-103 Washer 1
22 G62-6-4504-101 Tube II 1
23 G62-6-4503-109 Tube I 1
24 G62-3-4300-107 Saddle Base 1
25 G52-6-1709-106 Knob 1
26 601-4-0040-034 Spring Pin 1
27 G62-6-4501-105 Tilt Screw 1
28 653-1-0127-409 Hex. Bolt 4
* G62-3-9901-108 Seal Kit, Hyd. Unit -
(*) Seal Kit Contents:
Item Description Qty.
2 Filler Screw 1
3 Oil Seal 1
A Seal 1
B O-ring 1
C Back-up Ring 1
D U-cup 1
E O-ring 1
F Back-up Ring 1
G O-ring 1
H Back-up Ring 1
I O-ring 1
J O-ring 1
K O-ring 1
Replacement Parts List for Model 5100815:
