GB - INSTRUCTION MANUAL
7. IMPORTANT INFORMATION FOR INITIAL OPERATION
Check the product for transport any damage. Notify the carrier if you find any transport damage.
Check the oil level of the compressor before useage. (Image K)
Position the compressor as close to the working area as possible to avoid long air hoses and
extension cords.
Intake air must be dry and clean.
After filling the air tank the compressor engine must cool down for 2-5 minutes to avoid over-
heating.
Mounting the wheels (3)
The enclosed wheels have to be mounted according to images C and D.
Mounting the stand (16)
Mounting the air filter (1)
Mounting the oil plug (12)
The enclosed rubber stands have to be mounted according to image E.
Remove the transport plug using a flat screwdriver or a similar tool (image H). Put the oil plug firmly
into the opening.
Remove the transport plug using a flat screwdriver or a similar tool (image F). Screw the air filter to
the compressor as shown in image G.
