Instrument and EC cartridge overview
Touch Screen
Maintenance door:
access to pump,
valves and tubing
Aspiration needle
Proximity sensor
Sample cover:
access to sample
aspiration unit
Front door:
access to
EC cartridge
compartment
Fluidic connector
Biosensor
EC cartridge
connector
EC cartridge
compartment
Lever arm
FOR DETAILED INFORMATION please refer to the EC 90 User Manual www.erbamannheim.com
PAGE 3
QUICK START GUIDE Series
EC 90
ELECTROLYTE
ANALYSER
The purpose of this guide is to provide essential information required for using the EC 90 series.
Nevertheless, operators are instructed to carefully read the user manual before starting operation. All
precautions, safety and operating instructions must be read, understood and followed.
