ERBA EC 90 - Start-up Procedure; Initial Component Removal; Valve Preparation; Internal Access and Connection

Log in with dummy account
Open maintenance door, remove
foam block & clamp pump tube
Remove tube clips from valves
V1, V2, V3 & V5
Start-up
3
5
2
4
6
FOR DETAILED INFORMATION please refer to the EC 90 User Manual
PAGE 4
Close maintenance door and left side
panel and connect to main power
1
www.erbamannheim.com
Confirm pump tube clamped and
tube clips removed
Remove cap & cap sealing from EC
cartridge and peel o sensor film
Confirm insertion & wait for
startup completion
Open front door and lift lever arm up
Insert new EC cartridge & close
lever and front door
Insert printer paper (optional)
PAGE 5
7
9
11
8
10
12
QUICK START GUIDE Series
EC 90
ELECTROLYTE
ANALYSER
Remove left side panel to access
valve V5
Set system settings
