Erbauer EBPW3000 - Operation

26
Connection to a socket-outlet
WARNING! Check the voltage! The voltage must comply with the
information on the rating label!
If using an extension cord it must be suitable for outdoor use with
sockets protected against water splashing. Ensure the extension cord is
ofthepropersizeandtypeforthemachine(≥1.5mm
2
)!
WARNING!
The electric supply connection shall be made by a qualified
electrician and comply with IEC 60364-1. It is recommended that the
electric supply to this machine should include a residual current device
that will interrupt the supply if the leakage current to earth exceeds 30 mA
for 30 ms or a device that will prove the earth circuit.
1. Set the on/off switch (12) to O position (Fig. 16).
2. Fully unwind the supply cord (6)
3. Connect the power plug (6) to a suitable socket-outlet.
Using the hose reel
WARNING! Always discharge the residual pressure from the high pressure
hose (13) by pressing the trigger lever (17a) of the trigger gun (17)
repeatedly before using the machine.
01
Unwinding the high pressure hose
WARNING! Always fully unwind and pull out the high pressure hose (13)
from the hose reel (14) completely for operation.
1. Slightly pull the crank handle (15) out from the hose reel (14) ( Fig. 17, step 1).
2. Unfold the crank handle (15) to allow its rotation ( Fig. 17, step 2 ).
3. Turn the crank handle (15) anti-clockwise to unwind the high pressure hose (13)
or pull the high pressure hose (13) out from the hose reel (14) for operation.
5063022018892-EBPW3000-PressureWasher-UM-V03.indd 265063022018892-EBPW3000-PressureWasher-UM-V03.indd 26 09-11-2022 14:09:0709-11-2022 14:09:07
27
02
Winding the high pressure hose
WARNING! Release the pressure in the high pressure hose (13) before
winding it up:
1. Set the on/off switch (12) to O position (Fig. 16).
2. Press the trigger lever (17a) of the trigger gun (17) repeatedly to
release the pressure remaining in the high pressure hose (14).
1. After use, turn the crank handle (15) clockwise to wind up the high pressure hose (13)
( Fig. 18, step 1).
2. Align the tabs on the crank handle (15) with the grooves on the housing. Slightly
push the crank handle (15) in to lock it in place (Fig. 18, step 2).
3. Fold the crank handle (15) .
03
Using the transportation handle
1. Press the lock-off button (3) to unlock the transportation handle (1) (Fig. 19, step 1).
2. Lift the transportation handle (1) to the desired height position (high/low) (Fig. 19,
step 2).
3. The transportation handle (1) clicks into place, and the lock-off button (3) raises
to its original position (Fig. 19, step 3).
Operation
WARNING! Do not operate the machine with a closed water tap! This
leads to dry running and subsequently damages the machine!
Kickback forces result from squeezing the trigger lever (17a)! Therefore,
always hold the trigger gun (17) with both hands!
Pay attention to safe posture! Improper handling can lead to injuries!
WARNING! Do not operate the machine when the ambient temperature is
below 0 °C. Water will freeze inside the machine and damage it.
