PRODUCT DESCRIPTION
1. Keyless chuck
1a. Chuck jaws
1b. Chuck sleeve
2. Torque adjustment ring
3. Function selection ring
4. Two-speed gear control
5. Forward/reverse rotation control
6. On/off switch
7. Handle
8. LED work light
9. Battery pack*
10. Power bar button*
11. Battery pack release button*
12. Belt clip
NOTE: * This may not be included in the supply scope.
01
TECHNICAL SPECIFICATIONS
Compact Combi Drill
Rated voltage: 18V d.c.
Rated no load speed: 0-480/0-1800/min
Impact rate: 0-7200/0-27000/min
Clutch positions:
Max. torque:
17
50 N.m
Chuck capacity:
Max. drilling capacity:
13mm
•
Wood 35mm
•
Steel 10mm
•
Masonry 13mm
Weight (without battery): Approx. 1 kg
Battery (may not be included)
Battery pack model: EBAT18-Li-2 EBAT18-Li-4
Battery voltage: 18V d.c. 18V d.c.
Battery capacity 2Ah 4Ah
Battery cell: 5pcs 10pcs
Weight: 0.4kg 0.7kg
Recommended ambient temperature range for charging: 5°C to 40°C
Ambient temperature range for tool and battery use: -10
o
C to 40
o
C
