21
BATTERY PACK POWER BAR
The Li-Ion battery pack (9) is equipped with a POWER BAR which is used to give an
indication of the battery pack’s remaining charge. Press the POWER BAR button (10) to
check battery charge as below. The LED will stay lit for approximately 5 seconds
.
10
76-100% Charge
51-75% Charge
26-50% Charge
5-25% Charge
under 5% Charge
Flash On Off
WARNING!
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack(s) from the product when
assembling parts or making any adjustments.
HOW TO USE THE BELT CLIP (B1, B2)
Screw the belt clip (12) on the tool with the screw. The belt clip can be hooked on your
belt or pocket, etc.
