RESIDUAL RISKS
Even if you are operating this product in accordance with all the
safety requirements, potential risks of injury and damage remain.
The following dangers can arise in connection with the structure
and design of this product:
a. Health defects resulting from vibration emission if the product
is being used over long periods of time or not adequately
managed and properly maintained.
b. Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects during use.
c. Danger of injury and property damage caused by ying objects.
WARNING! This product produces an electromagnetic eld
during operation! This eld may under some circumstances
interfere with active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend persons
with medical implants to consult their doctor and the
medical implant manufacturer before operating this product!
ASSEMBLY
01
UNPACKING
Unpack all parts and lay them on a at, stable surface.
• Remove all packing materials and shipping devices, if applicable.
• Make sure the delivery contents are complete and free of any damage. If you nd that parts
are missing or show damage do not use the product but contact your dealer. Using an
incomplete or damaged product represents a hazard to people and property.
• Ensure that you have all the accessories and tools needed for assembly and operation. This
also includes suitable personal protective equipment
WARNING!
The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is a
danger of choking and suffocation!
02
ASSEMBLY
WARNING!
The product must be fully assembled before operation! Do
not use a product that is only partly assembled or assembled with damaged
parts! Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not attach the battery pack (21).
NOTE:
Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
ASSEMBLING THE HANDLE BARS(FIG. A-D AND M)
Align the holes on the lower handle bar (4) with the ribs on the mower (Fig. A) to
assemble them with bolts (16b) and wheels (16a). (Fig. B)
Align the holes on the upper handle bar (1) with the holes on the lower handle bar (4)
(Fig. C) to assemble them with locking levers (17a) and nuts (17b).(Fig. D)
