Erbauer ERB052BTE - Page 8

1. ON/OFF (NVR) SWITCH
2. MOTOR OVERLOAD SWITCH
3. RUBBER (ANTI VIBRATION) FEET
4. THICKNESSER EXTENSION RAIL
5. CUT DEPTH CONTROL KNOB (PLANER MODE)
6. ADJUSTABLE (IN-FEED) TABLE (PLANER MODE)
7. CHIP EXTRACTION OUTLET
8. GUIDE FENCE
9. BLADE (CUTTER) GUARD
10. BLADE GUARD LOCKING KNOB
11. HEIGHT ADJUSTING HANDLE (THICKNESSING MODE)
12. BLADE GUARD ANGLE LOCKING KNOB
7
6
5
4
3
2
1
9
10
11
12
13
14
15
8
21
16
20
19
18
