13. FIXED (OUT-FEED) TABLE (PLANER MODE)
14. BLADE GUARD ARM ASSEMBLY
15. SAFETY INTERLOCK SWITCH
16. 45° FENCE ANGLE STOP
17. ANGLE POINTER
18. 90° FENCE ANGLE STOP
19. ANGLE GUIDE
20. FENCE ANGLE LOCK HANDLE
21. CABLE CLIPS
TECHNICAL DATA
Volts: 230V~50Hz
Power: 1280W
No load speed: 8,500min
-1
Max. planing width: 204mm
Max. depth of cut (planer): 3mm
Max. depth to cut (thicknesser): 2mm
Planing height: 5-120mm (Thicknesser)
Feed speed: 8m/min (Thicknesser)
Table size: 740x210mm (Planer)
250x204mm (Thicknesser)
Machine weight: 27.5kg
NOISE AND VIBRATION DATA
Sound pressure level: 92.9dB
Sound power level: 105.9dB
