WARNING! This product produces an electromagnetic
eld during operation! This eld may under some
circumstances interfere with active or passive
medical implants! To reduce the risk of serious or fatal
injury, we recommend persons with medical implants
to consult their doctor and the medical implant
manufacturer before operating this product!
Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Lock-off switch
2. On/off switch
3. Main handle
4. Dust extraction outlet
5. Flange cap
6. Cutting depth scale
7. Depth clamping knob
8. Mounting thread for
auxiliary handle
9. Fixed guard
10. Base plate
11. Spindle lock button
12. Guide wheel
13. Diamond cutting discs (x2)
14. Chisel
15. Spanner
16. Auxiliary handle
17. Dust extraction adaptor
18. Locking ange
19. Inner ange
20. Distance washers (x6)
21. Backing ange
22. Air vents
Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
