2. Open the base plate (10) and slide the ange cap (5) to the side. (Fig. A step 2 +
3, Fig. B)
3. Press the spindle lock button (11) fully and hold in position (Fig. C).
4. Loosen the locking ange (18) anti-clockwise with the provided spanner (15) (Fig.
D) and remove the locking ange (18), inner ange (19) and distance washers (20)
from spindle. Also remove the cutting discs if changing of discs or adjustment of
cutting width is required. (Fig. D, E)
5. Make sure that the backing ange (21) stays engaged on the spindle.
6. Place one cutting disc on the spindle and make sure that the bore of the cutting
disc ts to the backing ange (21) properly.
7. Place distance washers (20) (1~6 pcs) and then inner ange (19) on the spindle
which keep the desired distance between 2 cutting discs. Make sure that the
protruding side of the inner ange (19) faces outside. (Fig. F)
8. Place the second cutting disc on the spindle and make sure that the bore of the
cutting disc ts to the inner ange (21) properly.
9. Place the remaining distance washers on the spindle.
10. Fix all the attachments on the spindle by tightening the locking ange clockwise
to the spindle thread with the provided spanner (15) while pressing the spindle
locking button (11) (Fig. G step 1).
11. Slide the ange cap (5) downward to cover the hole and slide the base plate (10)
fully into the xed guard (9). (Fig. G step 2+3).
12. Fix the base plate (10) and the ange cap (5) with the depth clamping knob (7).
(Fig. H).
13. Turn the cutting disc by hand to test if it is rotating smoothly. The cutting discs
should not utter.
14. Switch the product on and let it run at no-load speed for about one minute to
ensure that the cutting discs and anges have been installed properly. If there is
any abnormal vibration or excessive noise, switch the product off and re-t the
cutting discs according to the above instructions.
03
Dust extraction (Fig. I)
WARNING! Attach a dust extraction device when using this product to
keep the working area clean!
Wear a dust mask when operating this product! Dust can be harmful to
health!
Attach a proper dust extraction device, e.g. a suitable vacuum cleaner attachment
(Ø35mm) to the dust extraction adaptor (17) and then attach to dust extraction outlet (4).
