Erbauer EWC1500 - Adjusting Cutting Parameters; Performing the Cutting Operation

27
01
Adjusting cutting width
The cutting width can be changed between 8 and 30 mm in 7 steps, depending on how
many of the 6 pcs distance washers are placed between the rst cutting blade and the
inner ange. Follow the same instruction of “Assembly - Cutting discs”.
02
Adjusting channel depth (Fig. K)
1. Loosen the depth clamping knob (7) anti-clockwise for approx. 180º.
(Fig. K step 1)
2. Raise/lower the base plate (10) and set the cutting discs to the desired depth - as
shown on the cutting depth scale (6). (Fig. K step 2).
3. Tighten the depth clamping knob (7). (Fig. K step 3).
WARNING! Always check the depth clamping knob (7) before working.
A loose depth clamping knob may cause serious injury.
03
Switching on/off (Fig. L)
The on/off switch is incorporated with a safety button to avoid accidental starting.
1. Push the lock-off switch (1) forward.
2. Press the on/off switch (2) to switch the product on.
3. To switch off the tool, release the on / off switch (2).
Operation
01
Cutting
WARNING! The power tool is only for cutting channels in a straight line!
1. Fit the correct cutting discs and ensure they are sharp and not damaged.
2. Set the depth and width of cut.
3. Hold the product with one hand on the handle (3) and with the other hand on the
auxiliary handle (16).
4. Switch the product on and wait until it runs at full speed before placing it on the
workpiece.
