ErGear EGCM5 - Grommet Base Assembly; Secure the Swivel Arm Assembly to the Pole

D
B
08a
UP
07
08b
Option B: Grommet Base Assembly
Step 2
Secure the Swivel Arm Assembly to the Pole
If there is no grommet hole on
your desk, position the pole (01)
on the mounting surface and
mark the hole. Drill a hole using
the drill bit in a diameter of
7/16in.(11mm)-33/64in.(13mm)
at the marked position through
the mounting surface.
09
09
07
02b
02a
01
25/32 in. - 2 23/64 in. (20-60mm)
7/16 in. - 33/64 in. (11-13mm) 7/16 in. - 33/64 in. (11-13mm)
02b
02a
01 02 03 04 05 06 07
