ErGear EGCM5 - Secure the Monitors to Swivel Arms; VESA Mounting and Spacer Usage

Step 3
Secure the Moitors to Swivel Arms
Alternate
Spacer
Setups
Secure 2 pcs bolts into the
top VESA holes on the back
of the monitor manually.
Please keep about 0.2 in.( 5mm)
spacing left for the two bolts.
4x4 in.(100x100mm)
TV1/TV2
TV3/TV4
3x3 in.(75x75mm)
G
(If needed)(If needed)
3 in. (75mm)x3 in. (75mm)
4 in.(100mm)x4 in.(100mm)
Phillips
Screwdriver
[Not Included]
D
Large
Allen Key
Large
Allen Key
06
0.2 in.(5mm) spacing left0.2 in.(5mm) spacing left
01 02 03 04 05 06 07
