WARNING: This product contains small items that may pose a choking hazard.
Before starting assembly, verify all parts are included and undamaged. Do not use
damaged or defective parts. lf you require replacement parts, please contact our
Technical Support at 1-800-651-9525 (US / CA), 44-808-196-3875 (UK) or
Customer Service at support@ergear.com.
• NOTE: Not all hardware included in this package will be used.
Electric Drill (Optional)
Drill Bit (Optional)
3/8 - 1 1/16" (10 - 27mm)
Base USB Cable
Bolt
M4 x 10mm
Large Allen Key
3/16” (5mm)
USB Pressure Plate
Tools Needed (Not lncluded)
Supplied Parts and Hardware
Step 1
Supplied Parts and Hardware
Step 2
Supplied Parts and Hardware
C-Clamp Brace C-Clamp
Bolt
M6 x 12mm Grommet Bolt
x 101 x 202 x 1A x 2B
x 1M3
x 203 x 204 x 6C
x 1D
04
To Next Page
