ErGear EGTS5B - Page 10

E
15/64 in (6mm)
Large Allen Key
E
13
12
11
02
Step 3
Install the Arm Assembly [12] to the Pole [02]
Warning: Slowly unfold the
arm to avoid any injuries.
