ErGear EGTS5B - Page 11

For Monitor with Curved
or Recessed Back
Step 4 Attach the Monitor Plates to the Monitors
For Monitor with Flat Back
Phillips
Screwdriver
(Not lncluded)
M-A
M-C
M-B
M-C
M-D
Step 5 Hang the Monitors to the Mount
HEAVY! You may need
assistance with this step.
15
