ErGear EGTS5B - Page 6

Supplied Parts and Hardware for Step 3
Supplied Parts and Hardware for Step 4
Supplied Parts and Hardware for Step 5
Supplied Parts and Hardware for Step 7 and Step 8
x3
B
Bolt
M6x12mm
(x1) 11
Cable Clip
5/32 in (4mm)
Small Allen Key
x1
D
13/64 in (5mm)
Medium Allen Key
x1
F
15/64 in (6mm)
Large Allen Key
x1
E
(x1) 12
Arm Assembly
(x1)
13
(x3) 14
(x3) 15
Monitor Connector
Bolt
M4x12mm
Bolt
M4x30mm
Monitor Plate
Bolt
M6x12mm
x12
M-A
x12
M-B
Washer
M4
Spacer
L13mm
x12
M-C
x12
M-D
15/64 in (6mm)
Large Allen Key
x1
E
