Demontage
Dismantling
30
– Place cardboard or similar beneath the fi-
xing to catch the screws and prevent them
falling between the lamps.
– Unscrew 8 screws.
– Die Kappen an Kopf- und Fußende des
Profils losschrauben.
– Unscrew the caps at the head and foot
ends of the profile.
Caution!
The screws are special screws for use
with plastic. Store them carefully and
reuse when reassembling.
08843 / 0
4
Hinweis:
Die spätere Montage der Liegeschei-
be ist einfacher, wenn die Abdeckkap-
pen am Drehprofil demontiert werden.
Am endgültigen Standort des Bräu-
nungsgerätes muss jedoch an Kopf-
und Fußende ausreichend Platz für
die Montage der Abdeckkappen vor-
handen sein.
5
Note:
Subsequent installation of the support
panel is simpler, if the caps have been
removed from the rotating profile.
However, when the sunbed is placed
in its final position, there must be suf-
ficient space at the head and foot ends
for mounting of the caps.
...
