Ergomotion Serta Motion Essentials - Base and Remote Overview; Component Identification; Remote Control Functions

4 5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord (D)
Power Supply (E)
base and remote overview
Foot Motor
Head Motor
Control Box
Wired
Remote
Head Motor Foot Motor
Control Box
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
Input
Power Cord
To remove control box, release
metal clip and unplug cords.
Wired
Remote Port
Input Cord
Connection
Power
LED Light
Head Motor
Port
Foot Motor
Port
If installing a split unit - see pages 9-10.
Lifts and lowers
foot portion of
the base.
Lifts and lowers
head portion of
the base.
