Ergotron LX HD - Page 4

888-45-198-W-01 rev.B • 02/14
4 of 12
a
bc
d
ef
13 mm
Ø 3/16"
(5 mm)
M8 x 80mm
2x
6
SVENSKA
Wood
CAUTION: Make sure the wall mount bracket is level,
 ush and snug to the wall surface. DO NOT OVERTIGHT-
EN THE BOLTS.
